V8 Dual 8 Inch Active Line Array Speaker

Model: V8. V8 is dual 8 inch active line array speaker. The box is made of multi-layer plywood with a black light textured finish. There are 5 pieces M8 screw suspension points on each end of the top and bottom, and two handles at the back of the box for easy movement. The bottom is equipped with a 35mm support seat and has a 20mm nut inside. The front grill mesh is coated with powder and equipped with dust-proof cloth. The dimension of V8 active line array speaker is 318mm (Width) * 567mm (Height) * 387mm (Depth). The net weight og V8 active line array speaker is 21Kg. This speaker is a full range system with built-in amplifier. The frequency response of dual 8 inch active line array speaker V8 is 55Hz~18KHz and the maximum sound pressure level of dual 8 inch active line array speaker V8 is 131dB. Dual 8 inch active line array speaker V8 has 2 pieces 8 inch bass speaker (voice coil 51mm) and one piece 3 inch tweeter (voice coil 75mm). The impedance of dual 8 inch active line array speaker V8 is 12ohm. The input sensitivity of dual 8 inch active line array speaker V8 is 1.23V. The output power of dual 8 inch active line array speaker V8 is 2*800W and the input connection method of dual 8 inch active line array speaker V8 is 1*XLR.

V8：

LF: 2*8 inch, voice coil 51mm, 12ohm.

HF: 1*3 inch, voice coil 75mm.

● 1 in 2 out 24bit@48kHz DSP

Parameter Balance: Peak, High/Low Frame, All Pass, Bandpass, Bandstop, High/Low Pass

·Frequency division filter: Butterworth, Linkwitz-Riley, Bessel, 12dB/oct to 48dB/oct

·Limiter: peak limiter, RMS limiter

● Power supply, AC220V-240V is available

● Professional Audio Class D Circuit
